HTRC | 20A Multi Battery Charger 12V/24V Multi Battery Charger /lifepo4/lead-acid/agm Battery Pulse Repair Charger

Introducing the HTRC 20 Amp Lithium Battery Charger – Your Essential Battery Companion for Cars, Boats, and Motorcycles!

[Easy Start]
Our 12V and 24V Lifepo4 and Lead-Acid (AGM/Gel/SLA..) Portable Car Battery Charger offers hassle-free operation with its one-button start feature. It delivers a maximum charging current of 20A, ensuring swift battery replenishment. For added safety, it automatically locks after 10 seconds to prevent accidental touches. Plus, its compact size makes it highly portable.

[Adjustable Current]
Customize your charging experience with our Car Battery Charger's 3-level adjustable current settings. You can select from (12V/5A, 24V/3A) to (12V/10A, 24V/5A) to (12V/20A, 24V/10A) to suit your specific battery needs.

[Versatile Compatibility]
This Trickle Charger is compatible with various battery types, including Lithium, Lifepo4, Lead-Acid (PB/AGM/GEL/EFB, MF, FLOODED, VRLA, SLA, wet batteries). It's ideal for a wide range of vehicles and equipment, such as cars, golf carts, motorcycles, electric motorcycles, motorboats, lawn mowers, forklifts, tractors, and more.

[Maintenance and Pulse Repair]
Keep your battery in optimal condition with the Maintainer/Pulse Repair function, which activates and safeguards your battery during the charging process. Trickle charging provides the final protective layer to ensure your battery reaches full charge safely.

[Temperature Detection and Safety]
Equipped with a built-in temperature sensor, our charger operates smoothly within a temperature range from -10°C (14°F) to 40°C (104°F). It offers multiple protection features, including temperature protection, low voltage protection, overvoltage protection, short circuit protection, overcurrent protection, and electrostatic spark protection, ensuring a secure charging experience.

[One-Year Warranty]
Your satisfaction is our priority, and we back our product with a one-year warranty for peace of mind.

Key Specifications:
- AC Input: 100V/240V~ 50/60 Hz
- Output Voltage: 12V/24V
- Compatible with Lithium/Lifepo4/Lead Acid (AGM, GEL, EFB, MF, Flooded, VRLA, SLA, and wet battery)
- Output Current: 12V 20A & 24V 10A
- Supports AH: 2AH-300AH (Larger capacity batteries may require longer charging times)
- Minimum Starting Voltage: > 1.0 V
- Power and Load: MAX 280 W
- Dimensions: 158 x 90 x 50mm (6.22 x 3.54 x 1.97 inches)
- Net Weight: 520g

[Schematic Diagram]
- Charge Voltage & Current: Real-time display of voltage or current
- Repair Mode: Repairs the battery
- Temperature:
- Win: Raises charge voltage when temperature is below -10°C (14°F)
- Sum: Reduces charge voltage when temperature is above +40°C (104°F)
- Test Mode: Automatically continues trickle charging when battery is nearly fully charged
- Complete Charging: Indicates "FUL" when the battery is fully charged
- Low Voltage: Alerts to low battery voltage or inability to hold power
